Problem Statement

Whiteboards are excellent tools for solving problems and organizing ideas, but are not portable and always readily available. As well, collaboration on a whiteboard requires multiple people to be present in the same room. While industry moves more and more towards remote work, current tools designed for remote collaboration are either expensive or lack flexible drawing functionality. Our augmented reality whiteboard allows for any flat surface to be turned into a fully functional whiteboard writing space. Full collaboration networking capabilities allows for multiple users to share a writing space in real time from separate locations, removing the need to be present in the same room. Our system gives the benefits that a whiteboard provides while solving the problems or portability, availability, and collaboration.

Block Diagram
Block

System Specifications

• Detects and displays location of pen within 1cm

• Capable of writing the letter "A" with a height of 2cm

• Pen of 10cm length, 2cm diameter, and 40 grams

• Headset that is comfortable to use for 2 hours

• PDF output that exactly matches whiteboard content

• Maximum collaboration latency of 3s

• Maximum processing latency of 300ms

Documentation

Preliminary Design Review

Our PDR Slide Deck

Midway Design Review

Our MDR Slide Deck

Complete Design Review

Our CDR Slide Deck

Final Project Review

Our FPR Slide Deck

Midway Report
Click the button below to view our midway report on Overleaf
View Report
Final Report
Click the button below to view our final report on Overleaf
View Report
Poster

Faculty Advisor

Jay

Jay Taneja

SDP Team 17

Jeff

Jeff Muri, CSE

Jackson

Jackson Perkins, CSE

John

John Shea, CSE

Peter

Peter Stanwicks, CSE
